NEW Tractor PTO Drive 15.5' Ft Forest Log Crane w/ 13K Capacity Logging Timber Wood Trailer
*** IN STOCK. AVAILABLE FOR IMMEDIATE PICKUP IN SAN MARCOS, CA WAREHOUSE @ $16,995 INCLUDING THE 15.5' CRANE + HEAVY DUTY LOGGING TRAILER 13,200+ LB CAPACITY.
NEW Tractor PTO Drive 15.5' Ft Forest Log Crane w/ 13K Capacity Logging Timber Wood TrailerModel: WPRT06
Max Outreach: 15.42' Ft
Lifting Moment, gross: 28 KNm
Lifting capacity at 13' (excl. grapple and rotator): 880lb
Lifting capacity at full reach (excl. grapple and rotator): 660lb
Valve Block: 5/7
Slewing torque: 7 KNm
Rotator: 3 Ton
Grapple: 0.18 m2
Slewing angle: 360°
Slewing cylinders: 4 PCS
Working pressure: 175 BAR
Crane's weight (without outriggers and valve block): 770lb
3-Point Linkage: Cat-1&2
A type outriggers weight: 374lb
B type outriggers weight: 462lb
Load capacity up to 40 km/h: 13,228lb
Length of loading area: 129.5"
Total length: 210"
Total width with standard wheels: 78"
Standard wheels 10.0/80-12
High of the bloster “S”: 47.25"
Number of the bloster “S” 3 sets
Height of the front gate: 51.2"
Centre distance between the tyres: 38.2"
Cargo Width at the top wagon: 67"
Cargo Width at the bottom trailer: 43.25"
Weight(without tyres): 1675lb
